平板支架
适用于三星Tab Active 5 Pro和4 Pro的RAM®锁定供电底座和底座
产品型号：RAM-HOL-SAM57CPKL-225-V7CU
适用于Samsung Tab Active 5 Pro 4 Pro的RAM® Locking Powered Dock Mount（RAM-HOL-SAM 57 CPKL-225-V7 CU）是一款全面的套件，包含在您的车队中部署Samsung Tab Active Pro系列所需的一切。它包含一个用于Tab Active 5 Pro/4 Pro的锁定RAM® USB-C Powered Dock、一个带背板和锁定臂的短C尺寸双球座、电缆夹和硬线充电器。底座使用USB Typ-C母电源连接器和集成pogo针在对接时为设备提供电力。它还具有简单的对接和脱离过程，只需将设备放入底座并将其推入到位即可。RAM® Powered Dock享有3年保修。
关注「RAMMount」公众号
📱 手机 / 平板 / 笔电车载支架全系产品
💬 回复关键词直达对应分类选购指南
📮 新品发布与选型建议第一时间推送
技术规格
| 产品型号 | RAM-HOL-SAM57CPKL-225-V7CU |
| 产品分类 | 平板支架 |
| 材质 | 船用级铝 高强度复合材料 |
| 兼容设备 | Samsung Tab Active5 Pro & 4 Pro |
| 插座间长度 | 2.5" |
| 球头尺寸 | B |
| 随附硬件（包装清单） | 2 Keys 装配五金件 Hardwire Charger with USB-C Connector Cable Clamp Kit |
| 包装类型 | 塑料袋 |
| 安装孔位 | 4-Hole AMPS: 1.181" x 1.496" |
| 输入电压 | 10-30VDC |
| 输出电压 | 5.42-9VDC |
| 输出电流 | 2.5A max |
| 输入接口 | Bare Wire |
| 输出接口 | USB Type-C Male |
| 输入线长 | 2.5 Meters |
| 输出线长 | 1 Meter |
| 工作温度 | -10°C to +70°C |
| 储存温度 | -40°C to +70°C |
| 认证 | CE Certification；E-Mark Certification；RCM Certification；FCC Certification；UL 62368-1 Certificaton |
| 法规认证 | Over Voltage Protection；Short Circuit Protection；Reverse Polarity Protection；RoHS Compliance；WEEE Compliance；SAE J-1113-5 Load Dump (Transient Voltage)；Moisture Resistant |
| UPC 条码 | 793442035968 |
| 产品特色 | Bundle includes the RAM® USB-C Powered Dock for Tab Active5 Pro & 4 Pro, short C size double ball mount with backing plate and locking arm, cable clamp, and a hardwire charger；Key locking powered dock supports the Samsung Galaxy Tab Active5 Pro, Tab Active4 Pro, and Tab Active Pro with factory Samsung case or with RAM® Skin™; powered through integrated pogo pin connector；Next gen charging with integrated pogo pin docking contacts that match the Tab Active5 Pro's pogo pads for a fumble-free charging experience and port-protection；Backed by a 3-year warranty |
