组件配件
GDS®模块化30- 64 V硬线充电器，带USB-A转DC电缆
产品型号：RAM-GDS-CHARGE-M55-V8BU
GDS®模块化硬线充电器配备USB Type-A母连接器和USB Type-A公连接器，是为任何GDS®车辆解决方案供电的理想解决方案。借助快速断开功能，可以轻松连接任何USB Typ-A充电线。当需要升级时，只需拔掉电源连接器并连接新的充电器组件即可避免重新布线。兼容任何5V设备与30 V-64 V输入范围。始终受到保护。始终连接。®
关注「RAMMount」公众号
📱 手机 / 平板 / 笔电车载支架全系产品
💬 回复关键词直达对应分类选购指南
📮 新品发布与选型建议第一时间推送
技术规格
| 产品型号 | RAM-GDS-CHARGE-M55-V8BU |
| 产品分类 | 组件配件 |
| 包装类型 | 塑料袋 |
| 输入电压 | 30-64VDC |
| 输出电压 | 5-9VDC* |
| 输出电流 | 2.5A max |
| 输入接口 | DC Plug |
| 输入线长 | 1.2 Meters including 2 Pole Flat Marine Connector |
| 输出线长 | .2 Meters |
| 工作温度 | -10°C to +70°C |
| 储存温度 | -40°C to +70°C |
| 认证 | E-Mark Certification，RCM Certification，IEC/UL 62368-1 |
| 法规认证 | Over Voltage Protection；Short Circuit Protection；Reverse Polarity Protection；RoHS Compliance；WEEE Compliance；SAE J-1113-5 Load Dump (Transient Voltage)；Moisture Resistant；FCC；CE；UKCA；IC |
| UPC 条码 | 793442054136 |
| 产品特色 | Hardwire charger includes USB Type-A female connector; 30V-64V input range, 5V output. In addition it includes the USB Type-A male connection and a 5.5mm DC connector；When upgrading devices, avoid rewiring by unplugging power connector and attaching new charger components；Part of the GDS® Ecosystem™ to keep devices protected, connected, and charged in nearly any application；Backed by a 3-year warranty |
