手机支架
适用于Zebra TC 8000/8300的RAM® Quick-Draw ™底座，配有RAM® Tough-Claw ™
产品型号：RAM-101-400-ZE9U
这款RAM® Quick-Draw™专为Zebra TC 8000和TC 8300扫描仪设计，由大型Tough-Claw™底座、双插座臂和圆形底座适配器组成。RAM Tough-Claw™是完美的安装底座，可以在圆形、方形、奇怪形状的轨道和杆上快速、轻松地免工具安装和拆卸。Tough-Claw™可夹在外直径为1- 1.14的轨道上。圆形底座适配器包含行业标准通用AMPS孔图案。该支架采用了RAM 1.5直径的专利橡胶球和插座系统，在双插座臂的两端都有调整点;这允许几乎无限的调整和完美的视角。
关注「RAMMount」公众号
📱 手机 / 平板 / 笔电车载支架全系产品
💬 回复关键词直达对应分类选购指南
📮 新品发布与选型建议第一时间推送
技术规格
| 产品型号 | RAM-101-400-ZE9U |
| 产品分类 | 手机支架 |
| 材质 | 船用级铝 |
| 兼容设备 | Zebra TC8000/8300 |
| 适配杆径 | .625" - 1.14" diameter |
| 插座间长度 | 4.66" |
| 球头尺寸 | C 尺寸（1.5"） |
| 插座臂长 | 中等 |
| 承重能力 | 常规使用 4 lbs，重载使用 3 lbs |
| 随附硬件（包装清单） | 装配五金件 |
| 包装类型 | 塑料袋 |
| UPC 条码 | 793442012853 |
| 产品特色 | Spring-loaded RAM® Quick-Draw™ holder provides easy removal of your Zebra TC8000 and TC8300；Includes small version of the RAM® Tough-Claw™, medium length C size RAM® double socket arm, and 2.5" round plate compatible with several RAM® device holders and cradles；Large version of the RAM® Tough-Claw™ base is designed to quickly clamp to round, square, and odd-shaped rails and bars ranging from 1" to 2.2" in outer diameter; rubber pads provide stable gripping and protection of mounting surface；Made of high-strength composite and stainless steel hardware for durability and reliability in the most demanding environments；Backed by a lifetime warranty |
