充电方案
GDS®模块化10- 30 V硬线充电器，带C型2.0电缆
产品型号：RAM-GDS-CHARGE-USBC-V7B1-1U
GDS®模块化10- 30 V硬线充电器（RAM-GDS-CHARGE-USBC-V7 B1 -1U）连接到电源，并为任何GDS®车辆解决方案提供电力。当需要升级时，快速断开功能使您可以通过拔下电源连接器并连接新的充电器组件来避免重新布线。与任何电流要求为2.5A或以下的5V设备兼容。始终受保护。始终连接。®
关注「RAMMount」公众号
📱 手机 / 平板 / 笔电车载支架全系产品
💬 回复关键词直达对应分类选购指南
📮 新品发布与选型建议第一时间推送
技术规格
| 产品型号 | RAM-GDS-CHARGE-USBC-V7B1-1U |
| 产品分类 | 充电方案 |
| 随附硬件（包装清单） | (1) 个 USB Type-C to Type-A 2.0 Cable |
| 包装类型 | 塑料袋 |
| 输入电压 | 10-30VDC |
| 输出电压 | 5-9VDC* |
| 输出电流 | 2.5A max |
| 输入接口 | USB Type-C |
| 输入线长 | 1.2 Meters including 2 Pole Flat Marine Connector |
| 输出线长 | .2 Meter |
| 工作温度 | -10°C to +70°C |
| 储存温度 | -40°C to +70°C |
| 认证 | E-Mark Certification，RCM Certification，IEC/UL 62368-1 |
| 法规认证 | Over Voltage Protection；Short Circuit Protection；Reverse Polarity Protection；RoHS Compliance；WEEE Compliance；SAE J-1113-5 Load Dump (Transient Voltage)；Moisture Resistant；FCC；CE；UKCA；IC |
| UPC 条码 | 793442024269 |
| 产品特色 | Hardwire charger features USB Type-A female connector；Comes with GDS® Genuine USB Type-C 2.0 Cable; featuring USB Type-A male connection and USB Type-C male connection；When upgrading devices, avoid rewiring by unplugging power connector and attaching new charger components；Part of the GDS® Ecosystem™ to keep devices protected, connected, and charged in nearly any application；Backed by a 3-year warranty |
